E17-15I-14MP - Female E-Line X Clamp Adapter

Material Type
Size

View Dimensions

Dimensions

OD Tube Size	A, in.	A, mm.	Product Weight
1	1.281	32.54	0.32
1.5	1.437	36.5	0.4
2	1.5	38.1	0.52
2.5	1.625	41.28	0.78
3	1.718	43.64	0.98
4	1.968	49.99	1.52
6	2	50.8	--

	VNE part number
OD Tube Size	304	316L
1	E17-15I-14MP1.0	E17-15I-14MP-6L1.0
1.5	E17-15I-14MP1.5	E17-15I-14MP-6L1.5
2	E17-15I-14MP2.0	E17-15I-14MP-6L2.0
2.5	E17-15I-14MP2.5	E17-15I-14MP-6L2.5
3	E17-15I-14MP3.0	E17-15I-14MP-6L3.0
4	E17-15I-14MP4.0	E17-15I-14MP-6L4.0
6	E17-15I-14MP6.0	E17-15I-14MP-6L6.0

Cad Model File	Click here to request 3D Step File
Material Type	316L
Size	1
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Clamp
OD Tube Size	1
Wall Thickness	0.065
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-17-15I-14MP
Wayland Part Number	W17-15I-14MP
Dixon Part Number	17-15I-14MP
Sanitary Solutions Part Number	SS17-15I-14MP
Sanitube Part Number	17-15I-14MP
A, in.	1.281
A, mm.	32.54
Product Weight	0.32

Cad Model File	Click here to request 3D Step File
Material Type	316L
Size	1.5
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Clamp
OD Tube Size	1.5
Wall Thickness	0.065
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-17-15I-14MP
Wayland Part Number	W17-15I-14MP
Dixon Part Number	17-15I-14MP
Sanitary Solutions Part Number	SS17-15I-14MP
Sanitube Part Number	17-15I-14MP
A, in.	1.437
A, mm.	36.5
Product Weight	0.4

Cad Model File	Click here to request 3D Step File
Material Type	316L
Size	2
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Clamp
OD Tube Size	2
Wall Thickness	0.065
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-17-15I-14MP
Wayland Part Number	W17-15I-14MP
Dixon Part Number	17-15I-14MP
Sanitary Solutions Part Number	SS17-15I-14MP
Sanitube Part Number	17-15I-14MP
A, in.	1.5
A, mm.	38.1
Product Weight	0.52

Cad Model File	Click here to request 3D Step File
Material Type	316L
Size	2.5
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Clamp
OD Tube Size	2.5
Wall Thickness	0.065
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-17-15I-14MP
Wayland Part Number	W17-15I-14MP
Dixon Part Number	17-15I-14MP
Sanitary Solutions Part Number	SS17-15I-14MP
Sanitube Part Number	17-15I-14MP
A, in.	1.625
A, mm.	41.28
Product Weight	0.78

Cad Model File	Click here to request 3D Step File
Material Type	316L
Size	3
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Clamp
OD Tube Size	3
Wall Thickness	0.065
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-17-15I-14MP
Wayland Part Number	W17-15I-14MP
Dixon Part Number	17-15I-14MP
Sanitary Solutions Part Number	SS17-15I-14MP
Sanitube Part Number	17-15I-14MP
A, in.	1.718
A, mm.	43.64
Product Weight	0.98

Cad Model File	Click here to request 3D Step File
Material Type	316L
Size	4
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Clamp
OD Tube Size	4
Wall Thickness	0.083
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-17-15I-14MP
Wayland Part Number	W17-15I-14MP
Dixon Part Number	17-15I-14MP
Sanitary Solutions Part Number	SS17-15I-14MP
Sanitube Part Number	17-15I-14MP
A, in.	1.968
A, mm.	49.99
Product Weight	1.52

Cad Model File	Click here to request 3D Step File
Material Type	316L
Size	6
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Clamp
OD Tube Size	6
Wall Thickness	0.109
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-17-15I-14MP
Wayland Part Number	W17-15I-14MP
Dixon Part Number	17-15I-14MP
Sanitary Solutions Part Number	SS17-15I-14MP
Sanitube Part Number	17-15I-14MP
A, in.	2
A, mm.	50.8

Cad Model File	Click here to request 3D Step File
Material Type	304
Size	1
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Clamp
OD Tube Size	1
Wall Thickness	0.065
Material-Type	304
Material Test Reports	COC Available for 304 Materials
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-17-15I-14MP
Wayland Part Number	W17-15I-14MP
Dixon Part Number	17-15I-14MP
Sanitary Solutions Part Number	SS17-15I-14MP
Sanitube Part Number	17-15I-14MP
A, in.	1.281
A, mm.	32.54
Product Weight	0.32

Cad Model File	Click here to request 3D Step File
Material Type	304
Size	1.5
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Clamp
OD Tube Size	1.5
Wall Thickness	0.065
Material-Type	304
Material Test Reports	COC Available for 304 Materials
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-17-15I-14MP
Wayland Part Number	W17-15I-14MP
Dixon Part Number	17-15I-14MP
Sanitary Solutions Part Number	SS17-15I-14MP
Sanitube Part Number	17-15I-14MP
A, in.	1.437
A, mm.	36.5
Product Weight	0.4

Cad Model File	Click here to request 3D Step File
Material Type	304
Size	2
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Clamp
OD Tube Size	2
Wall Thickness	0.065
Material-Type	304
Material Test Reports	COC Available for 304 Materials
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-17-15I-14MP
Wayland Part Number	W17-15I-14MP
Dixon Part Number	17-15I-14MP
Sanitary Solutions Part Number	SS17-15I-14MP
Sanitube Part Number	17-15I-14MP
A, in.	1.5
A, mm.	38.1
Product Weight	0.52

Cad Model File	Click here to request 3D Step File
Material Type	304
Size	2.5
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Clamp
OD Tube Size	2.5
Wall Thickness	0.065
Material-Type	304
Material Test Reports	COC Available for 304 Materials
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-17-15I-14MP
Wayland Part Number	W17-15I-14MP
Dixon Part Number	17-15I-14MP
Sanitary Solutions Part Number	SS17-15I-14MP
Sanitube Part Number	17-15I-14MP
A, in.	1.625
A, mm.	41.28
Product Weight	0.78

Cad Model File	Click here to request 3D Step File
Material Type	304
Size	3
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Clamp
OD Tube Size	3
Wall Thickness	0.065
Material-Type	304
Material Test Reports	COC Available for 304 Materials
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-17-15I-14MP
Wayland Part Number	W17-15I-14MP
Dixon Part Number	17-15I-14MP
Sanitary Solutions Part Number	SS17-15I-14MP
Sanitube Part Number	17-15I-14MP
A, in.	1.718
A, mm.	43.64

Cad Model File	Click here to request 3D Step File
Material Type	304
Size	4
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Clamp
OD Tube Size	4
Wall Thickness	0.083
Material-Type	304
Material Test Reports	COC Available for 304 Materials
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-17-15I-14MP
Wayland Part Number	W17-15I-14MP
Dixon Part Number	17-15I-14MP
Sanitary Solutions Part Number	SS17-15I-14MP
Sanitube Part Number	17-15I-14MP
A, in.	1.968
A, mm.	49.99
Product Weight	1.52

Cad Model File	Click here to request 3D Step File
Material Type	304
Size	6
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Clamp
OD Tube Size	6
Wall Thickness	0.109
Material-Type	304
Material Test Reports	COC Available for 304 Materials
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-17-15I-14MP
Wayland Part Number	W17-15I-14MP
Dixon Part Number	17-15I-14MP
Sanitary Solutions Part Number	SS17-15I-14MP
Sanitube Part Number	17-15I-14MP
A, in.	2
A, mm.	50.8
