E15WLI - Female E-Line Long Ferrule

View Dimensions

Dimensions

OD Tube Size	A, in.	A, mm.	Product Weight
1	1.75	44.45	0.36
1.5	2.031	51.59	0.38
2	2.312	58.72	0.65
2.5	2.5	63.5	0.8
3	2.687	68.25	1.04
4	3	76.2	1.62
6	4	101.6	--

Material Type	304
Size	1
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Weld
OD Tube Size	1
Wall Thickness	0.065
Material-Type	304
Material Test Reports	COC Available for 304 Materials
Passivated	Special Request
Cad Model File	E15WLI1.0.STEP
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	1.75
A, mm.	44.45
Product Weight	0.36

Material Type	304
Size	1.5
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Weld
OD Tube Size	1.5
Wall Thickness	0.065
Material-Type	304
Material Test Reports	COC Available for 304 Materials
Passivated	Special Request
Cad Model File	E15WLI1.5.STEP
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	2.031
A, mm.	51.59
Product Weight	0.38

Cad Model File	Click here to request 3D Step File
Material Type	304
Size	2
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Weld
OD Tube Size	2
Wall Thickness	0.065
Material-Type	304
Material Test Reports	COC Available for 304 Materials
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	2.312
A, mm.	58.72
Product Weight	0.65

Cad Model File	Click here to request 3D Step File
Material Type	304
Size	2.5
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Weld
OD Tube Size	2.5
Wall Thickness	0.065
Material-Type	304
Material Test Reports	COC Available for 304 Materials
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	2.5
A, mm.	63.5
Product Weight	0.8

Cad Model File	Click here to request 3D Step File
Material Type	304
Size	3
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Weld
OD Tube Size	3
Wall Thickness	0.065
Material-Type	304
Material Test Reports	COC Available for 304 Materials
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	2.687
A, mm.	68.25
Product Weight	1.04

Cad Model File	Click here to request 3D Step File
Material Type	304
Size	4
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Weld
OD Tube Size	4
Wall Thickness	0.083
Material-Type	304
Material Test Reports	COC Available for 304 Materials
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	3
A, mm.	76.2
Product Weight	1.62

Cad Model File	Click here to request 3D Step File
Material Type	304
Size	6
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Weld
OD Tube Size	6
Wall Thickness	0.109
Material-Type	304
Material Test Reports	COC Available for 304 Materials
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	4
A, mm.	101.6

Material Type	316L
Size	1
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Weld
OD Tube Size	1
Wall Thickness	0.065
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Cad Model File	E15WLI1.0.STEP
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	1.75
A, mm.	44.45
Product Weight	0.36

Material Type	316L
Size	1.5
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Weld
OD Tube Size	1.5
Wall Thickness	0.065
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Cad Model File	E15WLI1.5.STEP
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	2.031
A, mm.	51.59
Product Weight	0.38

Cad Model File	Click here to request 3D Step File
Material Type	316L
Size	2
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Weld
OD Tube Size	2
Wall Thickness	0.065
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	2.312
A, mm.	58.72
Product Weight	0.65

Cad Model File	Click here to request 3D Step File
Material Type	316L
Size	2.5
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Weld
OD Tube Size	2.5
Wall Thickness	0.065
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	2.5
A, mm.	63.5
Product Weight	0.8

Cad Model File	Click here to request 3D Step File
Material Type	316L
Size	3
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Weld
OD Tube Size	3
Wall Thickness	0.065
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	2.687
A, mm.	68.25
Product Weight	1.04

Cad Model File	Click here to request 3D Step File
Material Type	316L
Size	4
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Weld
OD Tube Size	4
Wall Thickness	0.083
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	3
A, mm.	76.2
Product Weight	1.62

Cad Model File	Click here to request 3D Step File
Material Type	316L
Size	6
Industry Standard	3A
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Female E-Line X Weld
OD Tube Size	6
Wall Thickness	0.109
Material-Type	316L
Material Test Reports	MTR’s Available Upon Request
Passivated	Special Request
Catalog File	Fittings Catalog.pdf
Alfa Laval Part Number	HDI-15WLI
Wayland Part Number	W15WLI
Dixon Part Number	15WLI
Sanitary Solutions Part Number	SS15WLI
Sanitube Part Number	15WLI
A, in.	4
A, mm.	101.6
