4" CLAMP SR NC AIR OPER BFV T304 EPDM SEAT

Attribute name	Attribute value
Material Type	304
Size	4
Seat Material	EPDM
Actuated Valve Fail Position Flow Pattern	Fail Closed
ID / OD Polish	20 µin Mechanical ID / 32 µin Mechanical OD
Connections	Clamp X Clamp
OD Tube Size	4
Wall Thickness	0.083
Material-Type	304
Seat-Material	EPDM
Country of Origin	China
Material Test Reports	COC Available for 304 Materials
Valve Pressure Rating	Max 145 psi
Valve Temperature Rating	15 - 200 F
Actuator Pressure Rating	72.5-145 psi
Actuator Temperature Rating	15-170 F
Control Top - Switch Type	External Proximity Switch Available
Actuated-Valve-Fail-Position-Flow-Pattern	Fail Closed
Cad Model File	51C-64.0AE-VBAC-XX.STEP
Catalog File	valves.pdf
A, in.	11.404
A, mm.	289.66
B, in.	10.558
C, in.	15.224
C, mm.	386.69
E, in.	6.063
E, mm.	154
