3.0" WELD SPRING CHECK VALVE EPDM

Attribute name	Attribute value
Size	3
Seat Material	EPDM
Industry Standard	3A;FDA Title 21, Paragraph 177.2600 / Class VI
ID / OD Polish	32 µin Mechanical ID / 32 µin Mechanical OD
Connections	Weld X Weld
OD Tube Size	3
Wall Thickness	0.065
Material-Type	316L
Seat-Material	EPDM
Country of Origin	TAIWAN
Material Test Reports	AVAILABLE UPON REQUEST
Valve Pressure Rating	145 PSI
Valve Temperature Rating	15°F to 200°F
Cad Model File	Click here to request 3D Step File
Catalog File	valves.pdf
Product Weight	6.25

Size

3

Industry Standard

3A;FDA Title 21, Paragraph 177.2600 / Class VI

Connections

Weld X Weld

Wall Thickness

0.065

Seat-Material

EPDM

Material Test Reports

AVAILABLE UPON REQUEST

Valve Temperature Rating

15°F to 200°F

Catalog File

valves.pdf
